Xflex Twin

Xflex Twin

Our 5 axis CNC solution with two adjacent machining units.

As part of the Xflex platform, the Xflex Twin is a solution with 2 adjacent units, that doubles the throughput with better floor space usage. By doing so, we do not sacrifice any flexibility as each 3axis unit is completely independent.

The Xflex Twin is an optimum solution for high productivity scenarios of prismatic parts.

  • High adaptability to different production scenarios, by means of a modular platform that allows multiple spindles per machining unit, and up to two adjacent machining units. Independent spindle Z axis available for twin spindle configuration.
  • Compatible with Dry, MQL or high-pressure coolant machining.
  • Design focused on favoring chip shedding.
  • Ergonomic design for tool change and maintenance activities.
  • Suitable configuration for gantry, robot, or manual load.

  • 4 or 5 axis machining center. All linear axes provided with linear scales.
  • Tool interface HSK-63, HSK-80 or HSK-100. Other interfaces upon request.
  • Motorized or conventional spindle.
  • Chain type automatic tool changer with 24 or 36 tools. Tool capacity can be upgraded upon request.
  • Multiple tool breakage detection systems (laser, mechanical check, tool monitoring, etc.).
  • Tool presence control in the tool exchange position between spindle and magazine.
  • Unobstructed chip shedding designed for MQL machining.
  • Totally sealed stainless steel front guarding with no horizontal surfaces.
  • Honeycomb bed design so chips fall directly to the conveyor.
Xflex Twin

Machining unit

  • 3 axis unit (X/Y/Z).
  • 1 or 2 spindles. Limited by the part swing diameter and machining process tolerances.
  • 1 or 2 units, depending on the production volumes.

​​​​​​​Fixture options

  • 1 or 2 fixtures (one side only). Limited by the part swing diameter and machining process tolerances.
  • Axis: A / B / A+B.

Load/unload options

  • Gantry load, by means of a loader integrated in the machine design.
  • Robot load.
  • Manual load. Directly to the fixture or by means of a loader integrated in the machine design.
1
2
3
  1. 1 Machining unit

    • 3 axis unit (X/Y/Z).
    • 1 or 2 spindles. Limited by the part swing diameter and machining process tolerances.
    • 1 or 2 units, depending on the production volumes.
  2. 2 ​​​​​​​Fixture options

    • 1 or 2 fixtures (one side only). Limited by the part swing diameter and machining process tolerances.
    • Axis: A / B / A+B.
  3. 3 Load/unload options

    • Gantry load, by means of a loader integrated in the machine design.
    • Robot load.
    • Manual load. Directly to the fixture or by means of a loader integrated in the machine design.
